#ICF BLOCKS SIZES PLUS#
The Reinforcer is compatible with Amvic’s Standard R22 ICF brick ledge forms in both 6” and 8”, the Amvic R30 Plus 6” and the fabricated brick ledge extension. Attach the corner block to the adjacent standard blocks using Advantage ICF multi-straps as described in figure 22. The Amvic Brick Ledge Reinforcer eliminates the horizontal rebar and stirrups in the ledge area allowing the Reinforcer to be easily placed into the form in one step providing cost savings of up to 30% when factoring in materials and labor with pre-bent or field fabricated rebar reinforcement. Conventional brick ledge forms must be reinforced with a line of horizontal rebar and stirrups between the horizontal bars in both the ledge and the wall area of the brick ledge form. EPS bead is expanded using steam in special molds to create the different shapes and sizes of ICF blocks. It is a single pre-assembled, 4ft (1.2m) long deformed welded wire reinforcement piece that is placed directly into Amvic’s brick ledge. Not only on the energy-efficiency and disaster resilience, but in manufacturing too. The Amvic Brick Ledge Reinforcer is an engineered ICF brick ledge reinforcement system that is designed to replace conventional rebar in the Amvic ICF brick ledge forms. Rigid insulation panel for under slab depressurization systemsīrick Ledge Reinforcer for ICF construction The unique feature of the Knockdown ICF System is that forms ship flat in bundles and the appropriate bridges are then used to create the needed form core size. High Density Flat Sheet Rigid Foam InsulationĮxterior Insulation Panel With a Vertical Drainage System BuildBlock Knockdown ICF System is a patented ICF building system that uses interlocking EPS foam blocks to create a formwork for reinforced concrete walls. High Density Rigid Foam Reflective Insulation Nudura ICF Products provide ease of installation and ensure the project meets the design requirements.Ampex Insulated Hydronic Radiant PEX PanelĬarbon Graphite Embedded EPS for Exterior Wall Insulationįlat Sheet Rigid Foam Insulation With Integrated Furring Amvic Insulated Concrete Forms (ICF) are stay in place formwork manufactured using two 3.25 (83mm) Type II/Type 2, closed cell, Expanded Polystyrene (EPS) panels connected by polypropylene webs placed at 8 (203mm) on center.
Nudura also offers our line of panel ICF products for different building scenarios. We are so confident that we want you to see how we stack up! Nudura offers ICF products and accessories that make the building process easier with our technology that can’t be found with other ICF formwork products on the market.Īll Nudura Forms have our innovative DURAFOLD, DURAMAX, DURALOK Technology®, and a 4-Way Reversible system giving you a form that can’t be matched. The complete range of Nudura ICF Products has been used throughout North America for homes, schools, medical facilities, military projects, hotels and more. The Perfect Block offers 6 sizes ranging from 6 block for small projects to 10 for special interest applications in government. We manufacture a range of product and accessories for a variety of applications which provide, maximum energy efficiency, superior strength, healthier indoor working and living environments and a structure that offers lower overall maintenance costs over its lifetime compared to traditional building applications.
Nudura ICF products offer contractors and developers, the ability to speed up the building process, reduce waste, and deliver architectural impact. Nudura is a global leader of Insulated Concrete Form products and accessories for residential, commercial, medical, and educational structures, along with a variety of other structure types.
